ABB 1MRK000614-AB Power Supply Module | Relion 670 Series

Product Description

Overview

The ABB 1MRK000614-AB is a robust internal power supply module designed for ABB Relion 670 and 650 series protection relays. This module converts substation battery voltages into precise internal voltages required for reliable operation of IED processors and I/O boards. Engineered for high availability, it ensures uninterrupted relay functionality under grid disturbances and voltage variations.

Key Features

Wide Input Voltage Compatibility
Supports a broad input range of 48–250 V DC and 100–240 V AC, enabling deployment across global substation standards without additional adapters.

Advanced Surge and Noise Protection
Includes integrated suppression against high-frequency transients and temporary voltage surges to safeguard sensitive electronic circuits.

Built-in Monitoring and Diagnostics
Equipped with internal voltage supervision and a fail-safe binary output ("Watchdog" contact) to signal critical power supply faults.

High Efficiency with Low Heat Output
Switching-mode design reduces thermal stress on the enclosure, enhancing reliability and extending MTBF of connected components.

Bridging Time for Event Capture
Provides short-term energy storage (>40 ms) to maintain relay operation during momentary power loss, ensuring proper logging and GOOSE communication continuity.

Technical Specifications

Applications

Ideal for substation protection relays in power distribution, transmission, and industrial automation where high reliability and precision voltage conversion are critical.

FAQ

Q: Can this module be used with ABB Relion 650 series relays?
A: Yes, the 1MRK000614-AB is fully compatible with both 670 and 650 series units.

Q: Do I need to match the revision code when replacing the module?
A: Always ensure the revision (e.g., R00) matches your existing hardware to avoid terminal or logic mismatches.

Q: What is the expected lifespan of this module?
A: With proper operating conditions, the MTBF aligns with ABB’s standard IED reliability, typically exceeding 10 years under normal substation environments.

Comparison with Similar Modules
Compared to older ABB power supply modules, the 1MRK000614-AB offers enhanced surge immunity, integrated diagnostics, and higher efficiency with lower thermal output.
