ABB 1MRK002266-AAr00 Power Supply Module | Relion 670 Series

Product Description

Overview

The ABB 1MRK002266-AAr00 is a precision-engineered Power Supply Module (PSM) designed for ABB Relion 670 series IEDs, including RED670, REL670, and REB670 models. It ensures stable, regulated DC power for all internal processing, communication, and I/O components, guaranteeing reliable operation in critical substation environments. Built for high availability, it maintains relay functionality under voltage fluctuations and system disturbances.

Key Features

• Wide input voltage compatibility for DC and AC sources

• High-efficiency switching to minimize heat and extend component life

• Multi-layer fault protection including overvoltage, short-circuit, and reverse polarity safeguards

• Integrated internal supervision with health monitoring and failure signaling

• EMC compliant, with surge protection up to 4 kV

• Rugged construction for substation and harsh environmental deployment

Technical Specifications

Performance Highlights

• Converts substation battery or AC power into stable internal voltages

• Minimizes thermal stress through advanced switching design

• Communicates operational status to SCADA via internal fail contact

• Survives voltage dips and power surges without interruption

Application Scenarios

• Main power source for RED670, REL670, REB670 relay systems

• Integration in substation automation and busbar protection schemes

• Replacement or upgrade of existing PSM units in modular relay racks

• Provides stable DC supply for communication and protection modules

FAQ

Q: Can this module operate with both AC and DC inputs?
A: Yes, the 1MRK002266-AAr00 supports a wide range of AC and DC station power sources.

Q: How does the internal fail contact function?
A: It signals SCADA or relay systems if output voltage drops below operational thresholds or the module experiences a fault.

Q: Is this compatible with half-size and full-size Relion 670 racks?
A: Yes, it fits both standard modular relay rack sizes without modifications.

Q: How does this PSM compare with similar ABB modules?
A: This module offers extended input voltage range, integrated fail signaling, and superior surge immunity compared to earlier PSM versions in the Relion 670 series.
