ABB 216GD6la HESG324436M1/A Control Module

Product Overview

The 216GD6IA (Part Number HESG324436M1/A) is a high-precision data acquisition interface engineered for ABB’s premier Distributed Control Systems (DCS), specifically the Symphony and Advant Master series. This module acts as the critical sensory link between field instrumentation and the control logic, converting raw analog signals into high-resolution digital data. Designed for extreme versatility, the 216GD6IA handles a broad spectrum of input types, from standard current loops and voltage signals to direct thermocouple and RTD temperature sensors. Its robust galvanic isolation architecture ensures that electrical noise or ground loops in the field do not compromise the integrity of the system bus or central processing units.

Technical Specifications

• Module Identification: 216GD6IA

• ABB Part Code: HESG324436M1/A

• Input Versatility: Supports 4-20mA/0-20mA Current, 0-10V/±10V Voltage, Thermocouples, and RTDs

• Conversion Technology: High-resolution Analog-to-Digital (A/D) conversion for superior accuracy

• Isolation Barrier: Galvanic isolation between field-side channels and internal system bus

• Operational Temperature: -25°C to +55°C (-13°F to +131°F)

• System Architecture: Fully compatible with ABB Symphony and Advant Master DCS racks

• EMC Compliance: Industrial-grade electromagnetic compatibility for high-interference zones

• Diagnostic Support: Integrated status monitoring and signal out-of-range detection

• Maintenance: Modular "plug-and-play" design for rapid field replacement
