Product Description

The ABB FAU810 is a high-precision Flame Analysis Unit engineered to monitor and analyze flame conditions in industrial combustion systems. It interprets optical signals from ABB flame detectors, such as the SF810 series, ensuring safe and efficient operation in boilers, furnaces, and multi-burner installations.

Designed for integration into ABB AC800M platforms, the FAU810 provides real-time flame status to control systems, distinguishing between valid flame signals and background noise or spurious radiation. Its intelligent processing minimizes false trips and ensures continuous plant operation.

Key Features

Advanced Flame Signal Processing
The FAU810 evaluates flicker frequency, flame intensity, and stability to accurately detect the presence of combustion flames. Its algorithms differentiate between primary flame regions, background radiation, and multiple burner sources.

Rapid Response & Safety

• Ultra-fast response times (<1 second) suitable for critical safety applications

• Programmable flame-on/off thresholds for precise control and emergency shutdown logic

• SIL 3 capable when deployed with ABB flame scanner systems

Integration & Communication

• Supports multiple sensor inputs and redundant flame channels

• Provides analog 4–20 mA output for flame intensity and dry-contact relays for flame status

• RS-485 Modbus RTU communication enables seamless connection to DCS or PLC systems

• Compatible with ABB configuration software for live flame monitoring and tuning

Durability & Reliability

• DIN rail mounting with rugged housing suitable for high-temperature, electrically noisy environments

• Self-diagnostics constantly monitor hardware and sensor integrity

• Operational temperature range: -40°C to +85°C

Technical Specifications

Advantages

• Minimized Nuisance Trips: Advanced signal discrimination reduces unnecessary shutdowns

• Rapid Commissioning: Digital interface simplifies configuration and parameter tuning

• Durable Construction: Suitable for high-temperature, vibration-prone, and electrically noisy industrial environments

• Reliable Safety: Continuous self-diagnostics and dual-channel monitoring ensure flame presence accuracy

FAQ

Q: Which sensors are compatible with FAU810?
A: Compatible with ABB SF810 series flame scanners and similar optical detectors.

Q: Can FAU810 monitor multiple burners?
A: Yes. Dual-channel configuration supports multiple sensors for safety-critical applications.

Q: How does it communicate with control systems?
A: Provides analog 4–20 mA, relay contacts, and RS-485 Modbus RTU output for integration with DCS or PLC.

Q: What fuels can it detect?
A: Supports coal, oil, natural gas, and other industrial fuels with adjustable flame flicker frequency.

Q: Is FAU810 suitable for extreme temperatures?
A: Yes. Rated for -40°C to +85°C, suitable for challenging industrial environments.
