ABB XFD213A 3BHE028122R0001 SSI Speed Sensor Interface Module

Product Description

Overview

The ABB XFD213A (3BHE028122R0001) is a high-precision SSI Speed Sensor Interface Module designed to capture accurate speed and position data from SSI-compatible encoders. It is widely used in advanced drive systems and high-performance motion control applications, such as ABB UNITROL platforms and ACS drive controllers.

Description

The XFD213A converts synchronous serial signals from encoders or speed sensors into reliable digital data for real-time processing by industrial controllers. With high-resolution feedback and low-latency response, this module ensures precise monitoring and control of motors, turbines, and other rotational equipment.

It is engineered to operate in harsh industrial environments, featuring robust galvanic isolation, IP65-level protection, and a wide operating temperature range. The module supports modular installation via DIN-rail or panel mounting and allows hot-swap replacement in compatible systems to minimize downtime.

Performance & Key Features

• High-Resolution Feedback: Provides up to 13-bit resolution or 0.01 RPM precision depending on the connected sensor.

• Wide Speed Monitoring: Supports rotational speeds up to 10,000 RPM.

• Synchronous Timing: Uses SSI protocol to deliver deterministic, time-aligned feedback for real-time process control.

• Reliable Communication: Interfaces with controllers over SSI and RS-485 protocols with high signal integrity.

• Electrical Protection: Galvanic isolation up to 1500V safeguards internal logic from high-power motor disturbances.

• Industrial Durability: Rated for -20°C to +85°C operation, with IP65 dust and water resistance or optional conformal coating.

• Compact and Flexible: Designed for DIN-rail or specialized panel mounting in high-density cabinets.

• Self-Diagnostics: Detects cable breaks, sensor failures, or communication errors to maintain process safety.

Technical Specifications

Applications

• High-precision motion control in ACS drives and UNITROL systems

• Motor speed and position monitoring in power electronics and industrial automation

• Real-time feedback for closed-loop control in turbines, pumps, and machinery

FAQ

Q: Can XFD213A be replaced without shutting down the system?
A: Yes, it supports hot-swap installation in compatible modular setups.

Q: What is the maximum speed range supported?
A: The module supports speeds from 0 up to 10,000 RPM.

Q: What level of electrical protection does it provide?
A: Galvanic isolation up to 1500V and IP65 environmental protection.
