Airpax T77310-12 Dual-Input Digital Tachometer

Description

The T77310-12 digital tachometer from Airpax is engineered for precise speed and frequency measurement in industrial environments. It supports dual-channel input and offers flexible analog and digital outputs for seamless integration.

Specifications

• Model Number: T77310-12

• Manufacturer: Airpax

• Product Type: Dual-input digital tachometer

• Input Channels: Single or dual channel configuration

• Frequency Range: 2 Hz to 30,000 Hz

• Sensor Inputs: Compatible with active or passive sensors

• Display Type: Auto-ranging LED display

• Power Supply: Operates on AC or DC input

• Mounting Style: DIN panel mount housing

• Analog Outputs: 4–20 mA, 0–20 mA, 0–10 VDC, 0–5 VDC

• Digital Output: RS232C serial communication

• Relay Setpoints: Two programmable relay outputs

• Accuracy: ±0.05% for display and relay functions

• Response Time: 100 to 200 milliseconds

• Operating Temperature: 0°C to 50°C

• Shock Resistance: MIL810C standard compliance

• Output Scaling: Expanded and suppressed analog scale

• Configuration: Field-adjustable conversion factors

• Housing Options: Optional industrial-grade enclosures available

Features

• Dual-Channel Input: Supports two independent measurement sources

• Nine Computed Functions: Offers advanced signal processing capabilities

• Flexible Output Options: Includes both current and voltage analog signals

• Serial Communication: RS232C port enables external system integration

• Function Indicators: LED indicators display operational status clearly

• Quick Response Time: Delivers fast feedback for dynamic control systems

• High Accuracy: Maintains precision across varying conditions

• User Configurable: Easily reconfigured for different applications

• Industrial Durability: Withstands vibration and shock in harsh settings

• Versatile Integration: Ideal for OEMs and automation control panels
