Allen-Bradley 1769-IF4 CompactLogix 4-Channel Analog Input Module

Manufacturer: Allen-Bradley
Product No.: 1769-IF4
Condition：in Stock
Product Type: CompactLogix 4-Channel Analog Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 1000g
Shipping port: Shanghai/Yiwu/Shenzhen
Warranty: 12 months

Quantity

Product Overview

The Allen-Bradley 1769-IF4 is a CompactLogix 4-channel analog input module designed for precise measurement of current, voltage, thermocouples, and RTDs. Each channel is individually configurable and supports selectable responses to input sensor faults, including optional operation of output devices during abnormal conditions. The module offers over-range and under-range detection, with high-resolution 15-bit analog input for accurate industrial control applications.

Technical Specifications

Parameter	Specification
Manufacturer / Brand	Allen-Bradley / Rockwell Automation
Part Number / Catalog No.	1769-IF4
Product Series	CompactLogix (Bul. 1768 / 1769)
Component Type	Analog Input Module
Number of Analog Inputs	4
Analog Input Types	Current, Voltage, Thermocouple, RTD
Analog Input Ranges	0–20 mA, 4–20 mA, 0–10 V DC, ±10 V DC, 0–5 V DC, 1–5 V DC
Analog Resolution	15-bit (signed)
Operating Temperature	0–60 °C
Storage Temperature	–40–85 °C
Relative Humidity	95 % RH max
Special Features	Over-range/under-range detection, configurable channels, selectable sensor fault response

Key Features

4 individually configurable analog input channels for versatile control applications.
Supports current, voltage, thermocouple, and RTD sensors.
Provides over-range and under-range detection for safe and reliable operation.
High-precision 15-bit input resolution ensures accurate data acquisition.
Selectable response to input sensor faults, including output device control during abnormal conditions.
Compact and reliable for CompactLogix systems, compatible with Bul. 1768/1769.
