Allen-Bradley 1769SC-IF4IH CompactLogix Analog Input Module

Manufacturer: Allen-Bradley
Product No.: 1769SC-IF4IH
Condition：in Stock
Product Type: CompactLogix Analog Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 286g
Shipping port: Shanghai/Yiwu/Shenzhen
Warranty: 12 months

Quantity

Product Overview

The Allen-Bradley 1769SC-IF4IH is a CompactLogix 4-channel analog input module designed for precise monitoring and control of industrial processes. It supports multiple analog input types, including 0–20 mA, 4–20 mA, 0–5 V, 1–5 V, and ±10 V, and offers 16-bit resolution for accurate measurements. Integrated HART communication enables programming and monitoring of HART-enabled devices directly from a workstation, eliminating the need for additional bridges or handheld tools.

Technical Specifications

Parameter	Specification
Manufacturer / Brand	Allen-Bradley / Rockwell Automation
Part Number / Catalog No.	1769SC-IF4IH
Component Type	Analog Input Module
Number of Analog Inputs	4
Input Signal Types	0–20 mA, 4–20 mA, 0–5 V, 1–5 V, ±10 V
Resolution	16-bit
Power Supply	120 mA @ 5 V DC, 60 mA @ 24 V DC
Dimensions (D×H×L)	87 × 118 × 16.104 mm
Weight	0.286 kg
Communication	HART-enabled
Special Features	User-selectable range, process alarms, timestamping, adjustable filter frequencies

Key Features

Supports multiple analog input types for versatile process monitoring.
16-bit resolution ensures precise and reliable measurements.
HART communication enables direct programming and monitoring of field devices.
Field device interface removes the need for additional HART bridges or handheld tools.
User-selectable ranges support custom scaling, process alarms, and adjustable filter frequencies.
Compact and lightweight, ideal for CompactLogix systems.
