Bently Nevada 147663-01 Touchscreen Display | 3500 Series

Product Description

Overview

The Bently Nevada 147663-01 is a precision display interface for the 3500 Series Machinery Protection System. Designed to present real-time system data on a VGA monitor with touchscreen functionality, this module enables operators to monitor, configure, and interact with machinery protection parameters efficiently. Its modular design allows flexible mounting in multiple configurations, making it suitable for control rooms and field applications.

Key Technical Features

Display and Interface

• Display Type: VGA-compatible touchscreen

• Customizable Interface: Users can configure screens, select data to display, and adjust graphical layouts

• Alarm Visualization: Provides immediate, real-time alarm notifications for rapid fault identification

• Data Logging: Records historical data for performance analysis and troubleshooting

Mounting Flexibility

• Face Mounting

• 19-inch EIA Rack Mount

• Panel Mounting

• Independent Mounting

• Rack Support: Up to two displays can be connected to each 3500 rack

Power Consumption

• Display Unit & Interface Module: Maximum 15.5 W

• -01 Display Unit: Maximum 5.6 W

• -02 Display Unit: Maximum 12.0 W

Operational Advantages

• Touchscreen Operation: Allows simple, direct interaction for parameter adjustments

• Industrial Compatibility: Designed for rugged environments with consistent performance in high-reliability systems

• Lightweight Construction: 0.55 kg for easy installation and minimal impact on rack load

Technical Specifications

Applications

Ideal for monitoring turbines, compressors, pumps, and other critical machinery. Enables operators to configure system parameters, view alarms, and track historical performance without direct interaction with front-end electronics.

FAQ

Q: How many displays can I connect to a single 3500 rack?
A: Up to two displays can be connected per rack.

Q: Does this module support custom graphical layouts?
A: Yes, the interface allows full customization of displayed data and graphics.

Q: Can this unit be panel mounted in the control room?
A: Yes, it supports face, panel, rack, or independent mounting for flexible installation.
