Configured for dual-channel vibration and gap signal monitoring in Bently Nevada 3300 machinery protection systems, the Bently Nevada 3300/16-15-01-03-00-00-02 (3300/16 Dual Vibration XY/GAP Monitor) provides direct physical/electrical execution for processing proximity transducer inputs and generating vibration monitoring functions. The monitor accepts 3300 series proximity transducer signals for radial vibration and position measurement.

Hardware Specifications

Eddy-Current Probe Scaling and Rotor Dynamics Monitoring

The 3300/16 Dual Vibration XY/GAP Monitor processes proximity transducer signals for shaft vibration and gap measurement applications. The monitor supports input from 3300 8 mm, 3300 XL 8 mm, and 7200 5 mm or 8 mm transducer systems.

The monitor configuration supports rotor dynamics analysis through dual vibration channel measurement and gap monitoring functions. Compatible 3300 XL NSv proximity transducer systems include a 3300 NSv probe, 3300 NSv extension cable, and 3300 XL NSv Proximitor Sensor for installations with restricted mechanical clearance.

The monitoring function applies to radial vibration, radial position, axial thrust position, tachometer, zero speed, and Keyphasor phase reference signal applications.

Frequently Asked Questions

Q: Which proximity transducer inputs are compatible with the 3300/16 monitor?
A: The specified configuration supports 3300 8 mm, 3300 XL 8 mm, and 7200 5 mm and 8 mm proximity transducer inputs.

Q: What measurement functions are supported by the Dual Vibration XY/GAP Monitor?
A: The monitor supports dual vibration measurement and gap signal monitoring for shaft position and vibration applications.

Q: What is the configured full-scale measurement range?
A: The specified configuration has a full-scale range option of 0-500 um pp.

Field Installation Guidelines

Install the monitor module into the designated 3300 rack position according to the rack configuration requirements. Confirm compatibility between the monitor input configuration and the connected proximity transducer system before operation.

Route vibration signal wiring separately from high-current conductors and switching circuits. Maintain proper shielding and grounding practices for proximity measurement circuits.

Verify the transducer type, cable connection, and Proximitor Sensor configuration before applying system power. Check mechanical installation conditions where reduced side-view or restricted mounting clearance exists.
