The Bently Nevada 330130-00-05-10-02-CN serves as the primary 3300 XL Proximitor Sensor utilized to execute static position and dynamic vibration measurements across 3300 XL 8 mm Proximity Transducer System platforms. The device supplies excitation to the eddy-current probe, interprets the reflected signal modulation, and provides a continuous analog voltage output proportional to the target gap distance.

Hardware Specifications

Proximity Transducer Mechanical Monitoring Attributes

The 330130-00-05-10-02-CN conditions raw radio-frequency signals to secure precise eddy-current probe scaling across the standard 2.0 mm linear field. Field calibration relies on verifying gap voltage alignment, maintaining a benchmark of -10 VDC at the physical midpoint of the target measurement track. Integrated shielding constraints inside the A308 aluminum casing provide cross-talk suppression and isolate tracking parameters from external electromagnetic fields affecting machine rotor dynamics.

Frequently Asked Questions

Q: Does this Proximitor Sensor require manual bench calibration with a specific matched probe and cable?

A: No. The 3300 XL series supports complete interchangeability across all standard probes, extension cables, and sensors, eliminating individual calibration matching.

Q: Is this module compatible with older, non-XL 3300 series transducer components?

A: Yes. The hardware is backward compatible and interchangeable with legacy non-XL 3300 series 5 mm and 8 mm transducer components.

Field Installation Guidelines
