Bently Nevada 350500 | 3500/05 System Rack | 19-inch EIA Rack | 14 Module Slots | Panel Mount

Product Description

Overview

The Bently Nevada 350500 is an integral component of the 3500 Machinery Protection System, designed to house and interconnect all monitoring modules (such as vibration, position, and speed monitors) and power supplies. This 19-inch EIA rack offers a highly reliable physical structure that provides the necessary Backplane for module communication and coordination with the Rack Interface Module (RIM). It ensures seamless integration of machinery protection and monitoring for industrial applications.

Key Features

• Module Slots: Accommodates up to 14 monitoring modules and 2 dedicated slots for Power Supplies, providing flexibility for a variety of monitoring needs.

• Redundant Power Supply: Equipped with redundant power supply capability, ensuring continued operation even during a power failure, increasing system uptime and reliability.

• Hot-Swappable Modules: Modules can be added or removed without interrupting the operation of other modules, reducing maintenance downtime and enhancing system flexibility.

• Rugged Construction: Built with a durable aluminum frame and integrated cooling vents for optimal performance in challenging environments such as power plants and refineries.

• Flexible Logic Support: The backplane supports advanced "Alert" and "Danger" relay logic, enabling the creation of complex machinery trip schemes for enhanced protection.

Breakdown of Part Number: 350500-00-00-00-01-01

This part number represents a specific configuration of the 3500/05 Rack based on the Bently Nevada ordering system:

• Rack Size - 00: Full-size Rack (19-inch EIA rack with 14 available module slots).

• Mounting Option - 00: Panel Mount (Rack mounts into a rectangular cutout in a panel).

• Agency Approval - 00: None (No hazardous area certifications such as ATEX/IECEx).

• Reserved - 00: Reserved for future use/standard configuration.

• Display Option - 01: Internal Termination (Standard wiring interface).

• European Compliance - 01: CE Compliant (Meets European safety and EMC standards).

Technical Specifications

Applications

The Bently Nevada 350500 rack is primarily used in applications requiring the protection and monitoring of critical machinery, including:

• Power Generation: Ensuring continuous, safe operation of turbines, generators, and other vital systems.

• Oil & Gas: Protecting critical equipment like compressors, pumps, and motors from failure.

• Refining & Manufacturing: Safeguarding production equipment in industries with high vibrations, heat, and electromagnetic interference.

FAQ

Q: How many modules can be installed in the 3500/05 rack?
A: The rack can support 14 monitoring modules and 2 dedicated power supply slots.

Q: Is the 3500/05 rack suitable for hazardous environments?
A: This specific configuration (350500-00-00-00-01-01) does not have any hazardous area certifications like ATEX/IECEx. However, it is designed to operate in rugged industrial environments.

Q: Can I add or remove modules without shutting down the system?
A: Yes, the modules are hot-swappable, meaning they can be removed or inserted without interrupting the operation of other modules.
