The Bently Nevada 79748-01, also cataloged as the 79748-01 Recorder Output Alarm Relay Output Module, operates as a dedicated hardware component for temperature monitoring signal relay output within the Bently Nevada 3300 Machinery Protection System.

Hardware Specifications

Temperature Monitoring Relay Interface Characteristics

The 79748-01 module provides recorder output and alarm relay output functions within the Bently Nevada 3300 Machinery Protection System. The assembly supports temperature monitoring applications by transmitting monitoring status information and alarm conditions to external recording, annunciation, and control circuits.

The module operates with temperature monitoring assemblies to support detection of abnormal thermal conditions in rotating machinery components. Relay outputs provide discrete alarm signaling based on configured monitoring conditions, while recorder outputs support external data recording interfaces.

Signal wiring requires verification of output assignment, terminal connections, and electrical isolation requirements before system commissioning. Proper cable routing and grounding practices should be maintained to reduce interference in industrial monitoring environments.

Frequently Asked Questions

Q: Does the 79748-01 module directly measure temperature signals?
A: The module provides recorder and alarm relay output functions as part of the temperature monitoring assembly. Temperature measurement functions depend on the connected monitoring configuration.

Q: Is the 79748-01 compatible with Bently Nevada 3500 systems?
A: No. The module is specified for use with the Bently Nevada 3300 Machinery Protection System.

Q: What installation checks are required for relay outputs?
A: Verify terminal assignments, external circuit compatibility, wiring integrity, and grounding conditions before operation.

Field Installation Guidelines

Install the module within the compatible Bently Nevada 3300 monitoring rack or assembly location according to the system configuration requirements.

Route recorder output and relay wiring separately from high-current power cables and low-level sensor wiring. Maintain proper shielding and grounding practices where applicable.

Inspect module connectors, terminals, and field wiring before energization. Verify alarm relay operation and recorder signal transmission through the connected monitoring system.

Confirm all output assignments and external interface connections before placing the temperature monitoring system into service.
