Emerson Ovation 1C31223G01 16-Channel Relay Output Base Module

Product Description

Overview

The Emerson Ovation 1C31223G01 is a Relay Output Base Module designed for the Ovation Distributed Control System (DCS). It provides a robust interface for mounting and driving low-power relay outputs, enabling reliable control, alarming, indication, and interlocking functions in process control environments. This module is engineered for durability and flexibility, supporting multiple applications while maintaining high electrical isolation and signal integrity.

Key Features

• 16 Independent Relay Channels: Supports multiple field devices from a single base module.

• Low Power Operation: Optimized for minimal energy consumption while delivering high current output where needed.

• DIN Rail Compatible: Facilitates straightforward installation in standard control cabinets.

• G2R Relay Compatibility: Designed to house G2R-style relays for enhanced switching capability.

• Industrial-Grade Design: Rated for extreme temperatures, vibration, and shock conditions.

• CE Marked: Meets international safety and quality standards.

Technical Specifications

Applications

The 1C31223G01 module is commonly used for:

• Alarm and signal indication circuits

• Motor and valve control loops

• Interlocking critical process systems

• Relay-based automation and safety logic

FAQ

Q: How many relay channels does this module support?
A: The module supports 16 independent Form A relay channels.

Q: Can it operate in harsh industrial conditions?
A: Yes, it is rated for wide temperature ranges, high vibration, and shock tolerance.

Q: Is it compatible with Ovation DCS?
A: Absolutely, it integrates seamlessly with Ovation and Westinghouse Distributed Control Systems.

Q: Does it require a personality module (PMOD)?
A: No, the relay output configuration operates without a separate personality module, simplifying installation.
