Foxboro 900701-10-02 | 10 Meter Fiber Optic Patch Cable | Duplex ST Connector | EcoStruxure DCS

Shopify Product Title:

Foxboro 900701-10-02 | Fiber Optic Patch Cable | 10 Meter | Multimode ST Connector | EcoStruxure DCS

Product Description:

The Foxboro 900701-10-02 is a high-performance fiber optic patch cable, specifically designed for use within the Foxboro I/A Series and EcoStruxure Foxboro DCS (Distributed Control System). As a multimode fiber (MMF) assembly, this cable ensures reliable and high-speed communication for Fieldbus Modules (FBMs), Mesh network switches, and Baseplates over long distances, even in challenging industrial environments.

The 900701-10-02 is a pre-terminated duplex fiber optic cable, ideal for overcoming the limitations of copper-based wiring in noisy environments. It ensures EMI immunity, providing electrical isolation while supporting high-speed data transfer between remote I/O cabinets and the control room. This fiber optic cable is particularly suited for applications where traditional copper cables cannot be used due to interference from high-voltage equipment like motors and switchgear.

The "-10-02" suffix refers to the specific cable length (10 meters or approximately 33 feet) and connector configuration (ST to ST connectors).

Technical Specifications:

Key Features & Benefits:

1. EMI and RFI Immunity:
   Unlike copper cables, the 900701-10-02 transmits data using light, making it completely immune to Electromagnetic Interference (EMI) and Radio Frequency Interference (RFI). This immunity ensures that the signal remains unaffected even in environments with high levels of electrical noise, such as plants with high-power AC motors and switchgear.

2. Reliable Long-Distance Data Transmission:
   The multimode fiber design supports high-speed data transmission over significant distances without signal degradation. This is crucial in a DCS (Distributed Control System) environment, where data needs to be transferred between the control room and remote field I/O cabinets.

3. Mesh Network Compatibility:
   This fiber optic cable is a crucial part of the Foxboro Mesh network. It ensures low-latency, high-bandwidth connectivity for Foxboro Control Processors (CPs) and Industrial Ethernet Switches, enabling real-time data updates essential for effective control loop operation.

4. Rugged and Secure Connectors:
   The ST connectors feature a bayonet twist-lock mechanism that securely locks the cable into place. This prevents accidental disconnections caused by vibrations or movement, which is particularly important in industrial environments like power plants and oil refineries, where equipment vibrations are common.

5. Minimal Signal Latency:
   The 62.5/125 μm fiber provides the optimal balance for 100 Mbps to 1 Gbps communication speeds, ensuring fast transmission with minimal delay, crucial for the timely delivery of alarm data and control commands in real-time applications.

Installation and Connection Guidelines:

• Bend Radius:
  To maintain signal integrity, avoid sharp bends in the cable. The minimum bend radius should be at least 30 mm to prevent damage to the fiber core.

• Cleanliness:
  Fiber optic cables are sensitive to dust and debris. Always clean the ST connector tips with an alcohol wipe or a specialized fiber optic cleaner before connecting to ensure optimal performance.

• Polarity:
  Ensure correct polarity by connecting the "Transmit" (TX) lead at one end to the "Receive" (RX) port at the other end to ensure proper signal flow.
