General Electric DS200DCFBG1BLC Mark V DC Power Supply Board

General Electric DS200DCFBG1BLC Mark V DC Power Supply Board

  • Manufacturer: GE

  • Product No.: DS200DCFBG1BLC

  • Condition：in Stock

  • Product Type: DC Power Supply Feedback Board

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 1000g

  • Shipping port: Shanghai/Yiwu/Shenzhen

  • Warranty: 12 months

Product Description

Overview

The GE DS200DCFBG1BLC is a precision DC Power Supply Feedback Board designed for GE’s Mark V Speedtronic Control System. It delivers regulated DC power and signal conditioning to SCR bridges, ensuring reliable operation of gas and steam turbines. Built for industrial durability, this board manages multiple voltage rails and feedback signals, serving as a key interface between control logic and power conversion hardware.

Compact and rugged, the board supports high-current gate drive pulses, provides clean control power, and protects downstream electronics with integrated fusing and isolation barriers. It is widely used in turbine excitation, variable speed drives, and legacy Mark V installations requiring high reliability.

Technical Specifications

Attribute Specification
Manufacturer General Electric
Model Number DS200DCFBG1BLC
Product Type DC Power Supply Feedback Board
Series EX2000 / Mark V
Input Voltage 100–240 V AC, 50/60 Hz
Output Voltages +5 V, +12 V, +24 V DC
Output Power 50 W, 100 W, 250 W
Ripple & Noise ≤ 50 mV
Efficiency ≥ 85%
Operating Temperature -10°C to +70°C
Storage Temperature -40°C to +85°C
Condition New
Country of Origin USA
Instruction Manual GEI-100028C
Fuses Integrated high-speed protective fuses
Voltage Feedback ±15 V, +5 V isolated outputs for SCR gate and armature feedback
LED Diagnostics Status LEDs for power rails and fuse monitoring

Key Features

Multi-Voltage Distribution: Provides +5 V, ±15 V, and ±24 V DC outputs for control and SCR gate circuits.
Integrated Protection: High-speed fuses and galvanic isolation prevent overcurrent damage and protect sensitive electronics.
Feedback & Signal Conditioning: Converts voltage inputs into precise signals for the main controller using VCO circuits, ensuring high signal integrity.
Diagnostic Indicators: Onboard LEDs indicate power status and fuse integrity to reduce maintenance time.
Revision-Specific Design: The G1BLC variant offers enhanced voltage configuration and low-component layout for specialized industrial requirements.

Applications

  • Gas Turbine Excitation: Powers the magnetic field circuits in turbine generators.

  • Variable Speed Drives (VSD): Acts as the core power supply for motor control circuits.

  • Legacy System Maintenance: Supports older Mark V installations requiring high reliability and compatibility.

  • SCR Bridge Control: Supplies regulated gate drive energy for silicon-controlled rectifier circuits.

FAQ

Q: What input voltages does the DS200DCFBG1BLC accept?
A: 100–240 V AC at 50/60 Hz.

Q: What outputs are provided?
A: +5 V DC, ±15 V DC, and +24 V DC with various current ratings.

Q: Is the board protected against faults?
A: Yes, integrated fuses and isolation barriers prevent damage from overcurrent and voltage spikes.

Q: Can it be used in legacy Mark V systems?
A: Yes, it is compatible with Mark V, EX2000, DC2000, CB2000, FC2000, GF2000, ME2000, and AC2000 applications.
