Honeywell 8C-TAIM01 51306999-175 Analog Input Module

Honeywell 8C-TAIM01 51306999-175 Analog Input Module

  • Manufacturer: Honeywell

  • Product No.: 8C-TAIM01 51306999-175

  • Condition：in Stock

  • Product Type: Digital Input Module

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 260g

  • Shipping port: Shanghai/Yiwu/Shenzhen

  • Warranty: 12 months

Honeywell 8C-TAIM01 Analog Input Module

The Honeywell 8C‑TAIM01, also cataloged as the 51306999-175 Analog Input Module, operates as a Series 8 IOTA assembly for high‑precision analog signal acquisition in Experion PKS, C300, and PlantCruise systems.

Hardware Specifications

Parameter Specification
Model 8C‑TAIM01
Brand Honeywell
System Platform Experion PKS Series 8, C300, PlantCruise
Channels 16 analog input channels
Resolution 16‑bit A/D conversion
Accuracy ±0.1% typical, ±0.05% variant
Scan Rate 100 ms to 1 s configurable
Signal Types TC, RTD, mV, 4–20 mA
Input Impedance 250 Ω (current), ≥10 MΩ (voltage)
Isolation 2500 VAC channel‑to‑system, 2500 VAC channel‑to‑channel
CMRR >100 dB @ 50/60 Hz
Power Supply 24 VDC nominal (±20%)
Power Consumption ≤2.5 W
Dimensions 50 mm × 210 mm × 120 mm
Weight ~0.55–0.56 kg
Operating Temp 0 to +60 deg C
Storage Temp -40 to +85 deg C
Humidity 5%–95% RH non‑condensing
Mounting Vertical, C‑Series IOTA base

Cold Junction Compensation (CJC)

The 8C‑TAIM01 supports cold junction compensation for thermocouple inputs, ensuring accurate temperature measurement by compensating for ambient junction variations. Combined with high CMRR and optical isolation, the module maintains precise readings across multiple sensor types without cross‑interference.

Frequently Asked Questions

Q: Can the 8C‑TAIM01 be hot‑swapped in Series 8 racks? A: Yes, the module supports removal and installation under power (RIUP) within Series 8 IOTA assemblies.

Q: What is the maximum input protection level? A: Inputs tolerate up to ±30 V referenced to common without damage.

Q: Does the module require firmware updates? A: Firmware is managed at the controller level; the input module itself does not require independent updates.

Field Installation Guidelines

  • Use shielded cabling for analog loops to minimize EMI.
  • Maintain separation of wiring between voltage and current inputs.
  • Confirm backplane connector alignment before energizing.
  • Observe environmental limits of 0 to +60 deg C and 5%–95% RH non‑condensing.
  • Select conformal coating variants for corrosive or humid environments.
