Relay Module 216GA62/N221 ABB HESG112799R1

Product Overview

The 216GA62/N221 (identified by part number HESG112799R1) is a specialized high-speed auxiliary relay unit engineered for rapid fault isolation within ABB’s protection and control ecosystems. Designed to interface between low-level logic signals and heavy-duty switching gear, this module provides eight potential-free contacts capable of executing emergency shutdown and circuit breaker trip commands. It features a sophisticated dual-circuit architecture: a surge circuit for near-instantaneous contact closure and an economy circuit to drastically reduce holding power once the relay is latched, preventing thermal buildup during sustained activation.

Technical Specifications

• Manufacturer Model: 216GA62/N221

• ABB Order Code: HESG112799R1

• Contact Capacity: 8 Independent Potential-Free Tripping Contacts

• Operational Architecture: Integrated Surge and Economy (low-draw) circuits

• Logic Integration: Optional diode matrix support for direct external signal coupling

• Thermal Tolerance: -25°C to +55°C Operating Range

• Mechanical Dimensions: 180 mm x 60 mm x 30 mm

• Unit Weight: 0.5 kg

• Response Profile: High-speed actuation for critical fault isolation

• Application Compatibility: REG series protection racks and standalone industrial safety systems

Advanced Protection Features
