Schneider Electric Magelis XBTGT5230 | 10.4-inch HMI Touchscreen Panel

Shopify Product Title:
Schneider Electric Magelis XBTGT5230 | HMI Touchscreen Panel | 10.4-inch | Industrial Automation

Product Description

The Schneider Electric Magelis XBTGT5230 is a robust, high-performance Human-Machine Interface (HMI) designed for advanced industrial automation tasks. This touchscreen panel offers seamless integration with various automated systems, ensuring efficient operator interaction, data visualization, and control in demanding environments.

Key Technical Specifications

• Display Type:

• Backlit TFT Color LCD

• Display Size:

• 10.4-inch diagonal

• Resolution:

• 640 x 480 pixels (VGA)

• Color Depth:

• 65,536 colors

• Touch Panel Technology:

• Analog resistive touchscreen with multi-touch capability (software support)

• Processor:

• 266 MHz RISC processor

• Memory:

• 32 MB Flash (Application)

• 512 KB SRAM (Backup)

• Power Supply:

• 24 Vdc (isolated)

• Communication Ports:

• 1x RJ45 Ethernet port (TCP/IP)

• 2x USB ports

• 2x COM ports (RS232/RS485)

• Expansion:

• 1x Compact Flash (CF) card slot for additional storage

Features

• Connectivity:
  The XBTGT5230 is equipped with built-in Ethernet (TCP/IP), enabling remote monitoring and data transfer via FTP.

• Durability:
  The front panel is rated IP65 / NEMA 4X, offering protection against dust, moisture, and water jets, making it ideal for harsh industrial environments.

• Multimedia Support:
  Supports video playback and logging of data to external devices like CF cards and USB sticks.

• High-Quality Display:
  With its wide viewing angles and high contrast ratio, operators can easily monitor critical information from various positions.

• Advanced Software Compatibility:
  Configured using Vijeo Designer software, the XBTGT5230 offers features such as Recipe Management, Trend Graphing, and Multi-language interfaces. It is capable of communicating with various industrial devices and protocols (e.g., Modbus, Profibus, Ethernet/IP) for comprehensive control.

Applications

The Magelis XBTGT5230 is commonly used in industrial settings, particularly in conjunction with Schneider Electric Modicon PLCs. Its versatility also allows it to interface with third-party systems, making it a versatile solution for machine operators and system integrators across multiple sectors, including manufacturing, process control, and automation systems.

FAQ

What industrial systems is the XBTGT5230 compatible with?

The XBTGT5230 is compatible with Schneider Electric Modicon PLCs and can communicate with various third-party systems using Modbus, Profibus, and Ethernet/IP protocols.

Is the XBTGT5230 suitable for harsh environments?

Yes, with an IP65 / NEMA 4X rated front panel, the XBTGT5230 is designed to withstand dust, moisture, and water jets, making it ideal for industrial wash-down areas.

Can the XBTGT5230 handle remote monitoring?

Yes, the device features Ethernet (TCP/IP) connectivity, enabling remote monitoring via web interface and FTP data transfers.

What software do I use to configure the XBTGT5230?

The XBTGT5230 is configured using Vijeo Designer software, which allows users to create customized interfaces and manage connected devices.
