SCHNEIDER ELECTRIC MODULE TSXDSZO8R5

Product Description

The Schneider Electric TSXDSZ08R5 is a rugged and versatile digital output module designed for the Modicon TSX Micro PLC platform. Featuring 8 isolated relay outputs, this module is engineered to bridge the gap between low-level control logic and high-power field devices such as motor starters, large solenoids, and heavy-duty actuators. Its relay-based architecture provides superior electrical isolation, protecting your sensitive PLC processor from field-side voltage spikes and noise.

Built to perform in the most demanding industrial climates, the TSXDSZ08R5 boasts an impressive operating temperature range of -25°C to +70°C. Its lightweight yet durable "plastic and metal" hybrid construction ensures longevity without adding unnecessary bulk to your control cabinet. With a fanless cooling design and simple DIN rail mounting, this module is an essential component for engineers seeking a "fit-and-forget" solution for industrial automation and process control.

Technical Specifications

• Manufacturer: Schneider Electric

• Model Number: TSXDSZ08R5

• Product Type: Digital Output Module (Relay)

• Output Channels: 8 Channels

• Output Type: Relay (Dry Contact)

• Input/Logic Voltage: 24V DC (External power supply required)

• Phase: Single-phase compatible

• Connection Type: Integrated Screw Terminals

• Mounting: Standard 35mm DIN Rail

• Cooling: Natural convection (No cooling fans required)

• Environmental Ratings:

• Operating Temperature: -25°C to +70°C

• Storage Temperature: -40°C to +85°C

• Material Construction: Industrial-grade Plastic and Metal

• Dimensions: Compact form factor for TSX Micro expansion slots

• Weight: Approx. 250g

Application Scenarios

The TSXDSZ08R5 is optimized for high-reliability switching in various sectors:

• Manufacturing Plants: Controlling conveyor start/stop sequences and pneumatic manifold solenoids.

• Process Automation: Managing interlocks for pumps and valves in water treatment or chemical processing.

• Energy Management: Switching auxiliary power circuits and signaling alarms in remote substations.

• Harsh Environments: Ideal for unconditioned industrial sheds or outdoor enclosures where temperatures fluctuate significantly.
