Yokogawa AIP830-111 Operation Keyboard | Desktop HIS Interface

Product Description

Overview
The Yokogawa AIP830-111 is a precision-engineered operation keyboard designed for use with the CENTUM VP Desktop Human Interface Station (HIS). This keyboard provides dedicated tactile controls for single-loop operation, allowing operators to manage process loops, acknowledge alarms, and interact with plant systems efficiently. Unlike standard PC keyboards, it features an integrated USB speaker to provide clear system alerts separate from standard PC audio notifications.

Key Features

• 64 user-programmable function keys for process commands

• Dedicated window navigation and alarm acknowledgment keys

• Mode selection switch for Operator/Engineer access control

• Operation confirmation key for critical command validation

• Flat, industrial-grade layout optimized for continuous control room use

• Built-in USB speaker for alarm and alert sounds

Technical Specifications

Connectivity

• Dual USB Type-A connectors (both required for full functionality)

• Keyboard function: USB 2.0, Full-speed, Bus-powered

• Audio function: USB 1.1, Full-speed, Bus-powered

• Independent USB speaker for alarms and system sounds

Electrical & Mechanical

• Input voltage: 5V ±5% (via USB)

• Maximum current consumption: 1A

• Weight: 2.0 kg (keyboard only), 2.5 kg with optional VESA mount

• Chassis color: Black (Munsell N1.5 equivalent)

• Installation class: IEC 61010-1, Class I

Environmental Conditions

• Operating temperature: 5°C to 40°C

• Storage/transport temperature: -20°C to 60°C

• Humidity: 20%–80% RH, non-condensing

Applications
Exclusively designed for Yokogawa CENTUM VP HIS stations, the AIP830-111 enables "blind operation" for experienced operators, allowing efficient alarm management and process control without visual distraction.

FAQ

Q: Can the AIP830-111 be used with other HIS systems?
A: No, it is specifically engineered for the CENTUM VP Desktop HIS and may not function correctly with other systems.

Q: How many function keys can I program?
A: Up to 64 keys are fully user-definable for custom process commands.

Q: Does it support standard PC audio?
A: The keyboard provides a dedicated USB speaker for alarms; standard PC audio is separate.

Q: Is the VESA bracket included?
A: The keyboard is sold separately; the VESA bracket is optional and supports up to 10 kg.

Q: What is the difference between AIP830-111 and similar models like AIP830-112?
A: The AIP830-111 includes a Type B operation confirmation key, whereas the AIP830-112 may have alternative confirmation layouts or mode switch options.
