Yokogawa NFTP5S-00 Pressure Clamp Terminal Block

Description

The NFTP5S-00 from Yokogawa is a high-reliability terminal block module designed for connecting field wiring to I/O modules. It supports both input and output channels and ensures stable digital signal transmission in demanding environments.

Specifications

• Model: A2SAM105-H000 S2

• Manufacturer: Yokogawa

• Type: Pressure clamp terminal block

• Channels: 32-channel digital input/output

• Compatibility: Designed for Yokogawa FCN autonomous controllers

• Surge Protection: Available with or without surge absorbers

• Input Range – Thermocouple: -270 to 1820°C

• Input Range – RTD: -200 to 850°C

• Accuracy: ±0.1% of reading or ±0.25°C, whichever is greater

• Output Signal: 4–20 mA DC linear with temperature

• Power Supply Voltage: 10.5 to 45 V DC

• Ambient Operating Temperature: -40 to 85°C

• Storage Temperature: -50 to 100°C

• Response Time: ≤250 ms for 90% signal response

• Load Resistance: Maximum 600 Ω at 24 V DC

• Stability: ±0.1% of span per 12 months

• Weight: Approximately 0.3 kg

• Protection Rating: IP66 or IP67 depending on housing configuration

Features

• Secure Terminals: Pressure clamp design resists vibration and ensures stable connections

• High Channel Density: Supports 32 I/O points in a compact footprint

• Wide Tolerance Range: Operates across extreme temperature and voltage conditions

• Surge Protection Options: Enhances system reliability in noisy environments

• Flexible Signal Support: Accepts both thermocouple and RTD inputs with high accuracy

• Fast Response: Delivers quick signal conversion for real-time control

• Rugged Construction: Built for field deployment in harsh industrial settings

• Compact Design: Saves space in control cabinets without sacrificing performance
