The Yokogawa NFTR85-10 is an RTD input module designed for precise temperature measurement in industrial control systems. It supports multiple RTD types and integrates seamlessly with STARDOM controllers.
Specifications
Model Number: NFTR85-10
Manufacturer: Yokogawa
Input Channels: 8
Sensor Type: RTD (e.g., Pt100)
Input Signal: Resistance-based temperature signals
Resolution: 16-bit A/D conversion
Accuracy: High precision for process control
Connection Type: 2-wire or 3-wire RTD configuration
Operating Temperature: 0°C to +55°C
Storage Temperature: –20°C to +80°C
Humidity Range: 5% to 95% RH (non-condensing)
Mounting: DIN rail or modular rack
Weight: Approx. 0.3 kg
Features
Multi-Channel Input: Supports up to 8 RTD sensors simultaneously
High Accuracy: Ideal for critical temperature monitoring applications
Flexible Sensor Support: Compatible with standard RTD types like Pt100
Compact Design: Saves space in control panels
Stable Performance: Reliable operation in industrial environments
System Integration: Designed for use with STARDOM autonomous controllers
Easy Wiring: Supports both 2-wire and 3-wire configurations
