The S9681DB-0 by Yokogawa is a precision-engineered digital oscilloscope tailored for high-speed signal capture in electronics, telecom, and R&D environments. It delivers exceptional waveform resolution and versatile triggering capabilities for complex diagnostics.
Specifications
Model: S9681DB-0
Function: Digital Oscilloscope
Bandwidth: Up to 2 GHz
Sample Rate: 5 GSa/s
Memory Depth: Up to 2 Mbytes
Channels: 4 independent input channels
Vertical Resolution: 10 bits
Horizontal Resolution: 2.5 ns/div
Time Base Range: 5 ns/div to 10 s/div
Trigger Types: Edge, pulse width, delay, video, and more
Measurement Functions: Voltage, current, time, frequency, etc.
Dimensions: 300 mm × 250 mm × 80 mm
Weight: 3 kg
Features
High Bandwidth: Captures ultra-fast signals with up to 2 GHz bandwidth
Deep Memory: Stores long-duration waveforms for detailed analysis
Multi-Channel Input: Supports 4 channels for simultaneous signal monitoring
Precision Resolution: 10-bit vertical and 2.5 ns horizontal resolution for fine detail
Advanced Triggering: Multiple trigger modes for flexible signal isolation
Compact Form Factor: Space-saving design suitable for lab benches and test stations
Reliable Performance: Built for continuous use in demanding technical environments
