Z7136 Z-7136| HIMA |Digital Output Module

Manufacturer: HIMA
Product No.: Z7136
Condition：in Stock
Product Type: Digital Output Module
Product Origin: Germany
Payment:T/T, Western Union
Weight: 500g
Shipping port: Shanghai/Yiwu/Shenzhen
Warranty: 12 months

Quantity

HIMA Z7136 Digital Output Module

Overview

The HIMA Z7136 is a 16-channel digital output module engineered for use in HIMA Planar4 and HIQuad safety systems. Designed to meet SIL 3 and SIL 4 requirements, this module provides reliable and fast switching for actuators, alarms, and other field devices in safety-critical environments.

With dual redundant power channels and hot-swap support, the Z7136 ensures continuous operation and fault tolerance. Its high switching frequency up to 100 kHz makes it suitable for demanding automation tasks in oil & gas, chemical processing, and power generation industries.

Technical Specifications

Feature	Specification
Model Number	Z7136
Part Number	K9203
Product Type	Digital Output Module
Number of Channels	16 digital outputs
Output Voltage	24 VDC or 240 VAC
Output Current	2 A per channel
Switching Frequency	Up to 100 kHz
Safety Certification	SIL 3 (IEC 61508), TÜV-certified, AK7/SIL4 compliant
Hot Swap Support	Yes
Redundant Power Channels	Yes, dual independent paths
Dimensions (H × W × D)	100 mm × 100 mm × 50 mm
Weight	0.5 kg
Protection Class	IP20
Operating Voltage	24 VDC nominal
Operating Temperature	−25°C to +70°C
Storage Temperature	−40°C to +85°C
Certifications	CE, UL
Country of Origin	China / Germany (varies by supplier)
